{"NAME":"LSC Smart Power Plug with Energy Monitoring","GPIO":[0,0,0,0,2720,32,0,0,320,1,224,0,0,1],"FLAG":0,"BASE":18}

For more accurate energy consumption measurements this device requires power monitoring calibration.

This device uses a Tasmota incompatible module which needs to be replaced with an ESP. Besides the module, this process will require a heat gun, soldering tools and moderate soldering skill.

This powerplug has almost the same ordernumber as the other powerplug with the same name, apart from ending in .1. So pay attention which one you have as the internals are completely different.

This powerplug has a T1-S2-NL module including bluetooth. It needs to be replaced by an ESP-02S module.

As SEL is connected to AD, more than power is not available. So no voltage and ampere readings.

Function	Template	PCB	T1-S2_NL	ESP-02S
3.3	-	3.3	3.3	3.3
GND	-	GND	GND	GND
None	GPIO1	D-WIFI	TX1	TX0
LED 1	GPIO12	D-K	P9	D12
Relay 1	GPIO14	K1	P24	D14
Button 1	GPIO5	S1	P26	D5
BL0937 CF	GPIO4	CF	P6	D4
None	GPIO13	CF1	P8	D13
None	GPIO17	SEL	ADC	AD”
