Mirabella Genio 1002341 Plug
AU
Mirabella Genio 1002341

Available from:
Kmart.com.au




Manufacturer:
Mirabellagenio.net.au


GPIO #Component
GPIO00 None
GPIO01 None
GPIO02 Led1i
GPIO03 None
GPIO04 None
GPIO05 None
GPIO09 None
GPIO10 None
GPIO12 Relay1
GPIO13 Button1
GPIO14 None
GPIO15 None
GPIO16 None
FLAG None

Template

{"NAME":"Genio 1","GPIO":[0,0,56,0,0,0,0,0,21,17,0,0,0],"FLAG":0,"BASE":1}

This is a simple smart plug with the addition of a USB port. It is ESP8266 based featuring a On/OFF monenatary push button, 2 LEDs and 2 relays to switch the mains output. The USB port is ‘always on’ and is not access this from the ESP module. Opening up the device is easy. Two 2 screws are removed from the back panel then a small amount of gentle prying removed the cover exposing the components. Two more screws hold the PCB in place.

Wireless Flashing

The device can be flashed via Tuya-Convert – It’s suggested this be attempted first, as a significantly less dangerous option. It is suggested that this be attempted before ever connecting to an official app, but as of 28/10/2019 the official firmware updates delivered to the devices via the Genio app do not stop tuya-convert.

Serial Flashing

The ESP module is mounted on a pcb with all of the required pins exposed.

Photo of plug ESP8266 PINOUT

I was able to flash by connecting GPIO0 to GND while connecting my Serial Adaptor and flashing as per any other ESP device.

My prefered flashing method
